Product Series
Includes HL-GP Series (small to medium power), HL-G1/G2/G3 Series (medium to large power), and 4L-GF Series (large power & industrial use).
Power Range
Prime Power: 16 kW to 2000 kW; Standby Power: 17.6 kW to 2200 kW (some models offer higher).
Engine Models
4B3.9, 4BTA3.9, 6BT5.9, 6BTA5.9, 6CTA8.3, 6LTA8.9, QSZ13, NT/NTA855, KTA19/38/50, QSL9, QSK15/19/23/38/45/60, etc.
Engine Configuration
Cylinder Arrangement: 4 In-line (4/L), 6 In-line (6/L), 12V, 16V, etc.
Bore × Stroke (mm)
Common specifications: 102×120, 114×135, 130×163, 140×152, 159×159, 170×170, etc.
Fuel Consumption (L/h)
From approx. 6.7 L/h (low power) to 500 L/h (high power), depending on model and load.
Lubricating Oil Capacity (L)
From approx. 10.9 L to 204 L, increasing with engine displacement.
Coolant Capacity (L)
From approx. 18.4 L to 380 L, related to engine size and cooling requirements.
Dimensions - Open Frame (mm)
Minimum: ~1600×730×1110; Maximum: ~6200×2500×2740 (for large power units).
Weight (kg)
From approx. 650 kg to 17,250 kg, increasing significantly with power and structure.
Our Container Diesel Generators provide a complete, factory-tested power solution housed in rugged ISO-standard shipping containers. These fully self-contained units integrate the generator set, fuel system, control systems, and all ancillary equipment in a weatherproof, secure enclosure. Ideal for prime or standby power in harsh environments, remote locations, and applications requiring quick deployment, minimal installation, and maximum protection.
