Practical Genset 3 Phase 4 Wire , 50kw Electric 50kva Diesel Generator

Place of Origin CHINA
Brand Name CUMMINS
Certification CE
Model Number CN50GF
Minimum Order Quantity 1 set
Price usd 2500-3000/set
Packaging Details wooden case
Delivery Time 7-10 work days
Payment Terms L/C, D/A, D/P, T/T
Supply Ability 1000

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

WeChat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Dimension 2200*940*1450mm Net Weight 1000kg
Phase 3 Phase 4 Wire Rated Frequency 50Hz/60Hz
Rated Power 50KW/62.5KVA Rated Speed 1500rpm/1800rpm
Rated Voltage 400/230V Starting System Electric Starting
Highlight

Practical Genset 3 Phase

,

Genset 3 Phase 4 Wire

,

Electric 50kva Diesel Generator

Leave a Message
Product Description

Super Silent 50kw 3 Phase Electric Generator Diesel Power Genset 50kva Diesel Generator

Jining China Machinery Import And Export Company which is one of the largest diesel generator set manufacturers in China.

Our production capacity amounts to 9000 sets per year. We are specialized in making 20kva to 3000kva diesel generator sets under the brands of CUMMINS, PENTA, PERKINS, DEUTZ, DAEWOO, MTU, SHANGCHAI, FAWD, WEICHAI, JICHAI and other engines to equip with STAMFORD, MARATHON, LEROY SOMER, MECC ALTE, SIMENS, ENGGA... Our gensets mainly use DEEPSEA and SMARTGEN control panel.

According to your requests, they can be open type, silent type, mobile type and container type.

Our goal is to provide our users the best and most effective power solution. Customer needs is the direction of our efforts, customer satisfaction is our pursuit.

Any needs in land or marine emergency, backup and primary electric power, please don't hesitate to contact us.



Cummins Diesel Generator 50KVA

Genset Technical Data
Genset Model WP-C50GF
Rated Voltage 208/220/230/240V
Rated frequency 60HZ
P.F(COS) 0.8
Prime Power 45KVA
Standby Power 50KVA
Diesel Engine Technical Data
Engine Model Cummins 4BT3.9-G2
No. of Cylinders 6 cylinders, Vertical in line
Aspiration Turbocharged
Bore×Stroke 102mm x120mm
Displacement 3.9L
Compression ratio 17.3:1
Prime/Standby Power/Speed 40KW/44KW / 1800rpm
Speed Governor electrical
Cooling System Forced water cooling cycle
Fuel Consumption at 100% Load 221g/kwh@1800rpm
Alternator Data
Optional brands Stamford/Leroy Somer/Marathon/WellPower
Prime power 45KVA
Frequency/speed 60Hz/1800RPM
Exciter type Single bearing, Brushless, Self-excited with AVR
Power factor 0.8
Voltage adjust range ≥5%
Voltage regulation NL-FL ≤±1%
Insulation Grade H
Protection Grade IP23
Control Panel
Optional brands Deespea/Smartgen/ComAp



1.Q: What is your MOQ of this item?
A:1 Set

2.Q: What is the lead time?
A:7 working days after received the 30%T/T deposit

3.Q: Is it all right to make customer's own brand name?
A:We can be your OEM manufacture with your authorization of brand.

4.Q: Where is your Loading Port?
A:Qingdao or others

5.Q: What are your payment terms?
A:30% TT as deposit,70% TT before Shipment.

6.Q: What is your company's available production capacity?
A:100 Sets per month

7.Q:What's the warranty time of diesel generators?
A:12 Months or 1000 working hours
