Mobile Gasoline Power Generator 100kva Electric For Industrial

  • Mobile Gasoline Power Generator 100kva Electric For Industrial
  • Mobile Gasoline Power Generator 100kva Electric For Industrial
  • Mobile Gasoline Power Generator 100kva Electric For Industrial
  • Mobile Gasoline Power Generator 100kva Electric For Industrial
  • Mobile Gasoline Power Generator 100kva Electric For Industrial
  • Mobile Gasoline Power Generator 100kva Electric For Industrial
  • Mobile Gasoline Power Generator 100kva Electric For Industrial
  • Mobile Gasoline Power Generator 100kva Electric For Industrial
Place of Origin China
Brand Name CNMC
Certification EPA/CE/ISO And So On
Model Number CN800GF
Minimum Order Quantity 1 set
Price USD 2500-3000/set
Packaging Details wooden case packing
Delivery Time 7 days
Payment Terms L/C, T/T
Supply Ability 1000 sets per week

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

WeChat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Trailer Diesel Genertor Type Trailer
Engine International Brand Engine And Chinese Brand Engine Options Automatic Transfer Switch
Generator Type Household Power Portable Trailer Diesel Generator Color Customers' Request
Controller Smartgen DeepSea Keyword Gnerator
Control Panel LCD Digital Display Use Industrial And House
Body Aluminum Brakes Disc
Frame Steel Fuel Capacity Large
Lighting LED Power Output High
Power Source Electric Safety Features High
Suspension Heavy Duty Towing Capacity High
Trailer Type Generator Warranty Extended
Weight Capacity Heavy Wheels Heavy Duty
Highlight

Mobile Gasoline Power Generator

,

Gasoline Power Generator 100kva

,

Industrial Mobile Power Generator
Leave a Message
Product Description

HOT SALE Four Wheel Diesel Generator UK Brand Parkins Engine EPA Approved US Market 100kva Trailer Diesel Generator



Diesel generator Specifications
1. Powered by reliable engines
2. Branded alternator
3. Open type, silent type or super silent type generator
4. ISO, CE certified

Genset specs:
Engine Brands: Powered by Cummins,Powered by Perkins,Powered by Lovol,Powered by Deutz,Powered by Doosan, Powered by Mitsubishi, Powered by Kubota or other reliable Chinese engines such as Fawde and Laidong.
Rated output: 2 to 2,000kW/2 to 2,500kVA
Rated voltage: L-N 110 to 277V, L-L 220 to 480V
Rated frequency: 50/60Hz
Cooling method: closed water-cooled or air-cooled
Starting method: electric start or recoil start
Rated speed: 1,500/1,800/3,000/3,600rpm
Noise level: 56 to 75dB, 7 meters away

Alternator:
Brands: By Stamford, By Leroy Somer, By Mecc Alte and Keypower brushless alternator
Rated output: 8 to 2,000kW/10 to 2,500kVA
Rated voltage: L-N 110 to 277V, L-L 220 to 480V
Rated frequency: 50/60Hz
Phase: 3-phase, 4-wire or 1-phase, 2-wire
Connection: y or other type connection
Rated speed: 1,500/1,800rpm
Excitation: harmonic excitation or phase compound or brushless
Voltage regulation: AVR automatic
1.0% voltage regulation in static conditions (maximum)
Protection class: IP23
Control panel: Deepsea, ComAp, Smartgen



Diesel Generator Technical Data
Genset CN880GF Prime Power (KW) 800
Rated frequency(Hz) 50/60 Prime Power (KVA) 1000
Rated speed(Rpm) 1500/1800 Phase 3 Phase
Voltage 220/380V,230/400V,
240/415V,120/240V		 N.W (KG) 5200
Rated Current 1440A Size (L*W*H) mm 4000*1600*2200
Diesel Engine Technical Data
Brand/Original SDEC Type Water Cool,
Electric start
Engine Item No. SC33W1150D2 Cylinder No. 12
Displacement (L) 32.8 Bore and Stoke (MM) 180*215
Prime Power (KW) 781 Fuel Consumption 215(g/kw.h)
Standby power (KW) 860 Combustion Direct Injection
Governor Electronic Aspiration Type Air-to-air cooling
Alternator Technical Data
Brand/ Original Stamford copy/ Stamford original/Marathon/Leroy-Somer
Alternator Model HLF800 Protection IP23
Alternator Type Brushless sel-excited Insulation Class H
Phase / wire 3-phase& 4 line Factor 0.8
Control Module Specifications



Digital Control Module suitable for a wide variety of single, diesel or gas, gen-set applications.
Monitoring an extensive number of engine parameters, the module will display
warnings, shutdown and engine status information on the back-lit LCD screen and illuminated LEDs.


The control module gives digital readouts of:
Generator voltage Output frequency Engine hours run
Engine speed Battery voltage
The control module has indicators for failure information:
High water temperature Failure to start Battery charger failure
Automatic shutdown occurs under:
Low engine oil pressure High engine water temperature
Over speed/Low speed Failure to start after three attempts
