360KVA Mobile Generator Light Tower Multi Function Air Cooled

Place of Origin China
Brand Name CNMC
Certification EPA/CE/ISO
Model Number CN360GF
Minimum Order Quantity 1 set
Price USD 2500-3000/set
Packaging Details wooden case packing
Delivery Time 7 days
Payment Terms L/C, T/T
Supply Ability 1000 sets per week

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

WeChat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Dimension 1300*700*900mm Displacement 296cc
Engine Brand Loncin Engine Model LC168F
Engine Type Single Cylinder, Four Stroke, Air-cooled Frequency 50HZ
Fuel Tank Capacity 15L Net Weight 90kg
Noise Level 68dB(A)/7m Power Source Gasoline
Rated Power 7.5KW Rated Voltage 220V/380V
Start Mode Electric/Recoil Trailer Type Generator
Warranty 1 Year
Highlight

360KVA Generator Light Tower

,

Mobile Generator Light Tower

,

Multi Function Light Tower Generator

Leave a Message
Product Description

High Quality Mobile Diesel Generator Use Quality Warranty Yuchai Engine Trailer 360KVA Mobile Generator

  • 1, Diesel Engine (Cummins Brand)
  • 2, Generator/Alternator (With AVR)
  • 3, Standard Control Panel (Ordinary Type, LCD Type, ATS Type )
  • 4, Common Base with Canopy(Including Base Oil Tank)

Standard Accessories:

  • 1, Starting Battery and Connector Wire
  • 2, The Vibration Reduction Rubber Gasket
  • 3, Silencer
  • 4, Exhaust Elbow
  • 5, 8-hour Oil Tank
  • 6, Spare Part Case
  • 7, Technical Data
  • 8, Water Tank Radiator,The belt-driving Cooling Fan ,Fan Safety Shield
  • 9, Dry-type Air Filter
  • 10, Fuel Filter
  • 11, Lubricating Oil Filter
  • 12, Starting Motor
  • 13, Self-charging Generator
  • 14, Frequency Meter/Water-thermometer/Oil Pressure Gauge/Battery Voltmeter

Optional Accessories:

  • 1, Preheating Start System
  • 2, Diesel Engine Thermal Protection System
  • 3, Jacket Heater
  • 4, Speeding, High Temperature, High Oil Temperature, Low Pressure Alarm System
  • 5, Breaker
  • 6, Antifreeze Liquid
  • 7, Ground Wire
  • 8, Water Temperature Safety Device
  • 9, Machine Oil

Service Conditions:

  • -- Ambient Temperature: -25°C~40°C
  • -- Altitude: not exceed 1000 Meter
  • -- Rated Voltage: 230/380V or any voltage between 220-440V
  • -- Rated Frequency: 50Hz/60Hz
  • -- Insulation Class: B/F/H
  • -- Working Duty: S1(Continuous)
  • -- Humidity: Lower than 95%
Genset model CN400GF
Genset rated power 400KW/360KVA
Rated voltage 400/230V (adjustable)
Rated current 720 Amps
Frequency 50 Hz
Power factor 0.8 Lagging
Connecting type 3 phase 4 wire
Cooling system Closed cycle water-cooled with fan, water tank
Overall dimension (L×W×H) mm 3100×1100×1650
Gross weight (kg) 3200
Diesel Engine
Brand YUCHAI
Model YC6T660-D31
Engine type 6 cylinders vertical in Line, 4 stroke,
Aspiration Turbocharged and intercooled
Rotating speed 1500 RPM
Engine cooling system Water-cooled
Fuel system Electronic control injection
Starting method By 24V batteries
Engine filter system Dry type air filter,fuel filter, oil filter, water filter
Displacement(L) 16.35
Bore×Stroke(mm) 145×165
Compression ratio 14.0:1
100% Load fuel consumption (l/h) ≤100.9
Lube capacity(L) 52
Alternator
Brand SHANHUA
Model CN400
Excite type Brushless self-excited AVR regulation
Connecting type 3 phase 4 pole
Steady frequency change 0.50%
No load voltage ≥95%-105%
Steady voltage ≤±1%
Insulation class Class H
Protection grade IP23
