Multifunctional Yangdong Genset 40KW , Durable Diesel Powered Generator

Place of Origin CHINA
Brand Name Yangdong
Certification CE
Model Number HL40GF
Minimum Order Quantity 1 set
Price usd 2500-3000/set
Packaging Details wooden case
Delivery Time 7-10 work days
Payment Terms L/C, D/A, D/P, T/T
Supply Ability 1000

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

WeChat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Brand Yangdong Dimension 2200*940*1450mm
Frequency Various Frequencies Fuel Diesel
Power Various Powers Starting System Electric Starting Systems
Type Diesel Generator Weight 1200kg
Highlight

Multifunctional Yangdong Genset

,

Yangdong Genset 40KW

,

Durable Diesel Powered Generator

Leave a Message
Product Description

40KW Silent Generator Powered By Yangdong Stamford Super Silent 50kva Diesel Generator Price



Jining China Machinery Import And Export Company which is one of the largest diesel generator set manufacturers in China.

Our production capacity amounts to 9000 sets per year. We are specialized in making 20kva to 3000kva diesel generator sets under the brands of CUMMINS, PENTA, PERKINS, DEUTZ, DAEWOO, MTU, SHANGCHAI, FAWD, WEICHAI, JICHAI and other engines to equip with STAMFORD, MARATHON, LEROY SOMER, MECC ALTE, SIMENS, ENGGA... Our gensets mainly use DEEPSEA and SMARTGEN control panel.

According to your requests, they can be open type, silent type, mobile type and container type.

Our goal is to provide our users the best and most effective power solution. Customer needs is the direction of our efforts, customer satisfaction is our pursuit.

Any needs in land or marine emergency, backup and primary electric power, please don't hesitate to contact us.



Cummins Diesel Generator 50KVA

Genset Technical Data
Genset Model WP-C50GF
Rated Voltage 208/220/230/240V
Rated frequency 60HZ
P.F(COS) 0.8
Prime Power 45KVA
Standby Power 50KVA
Diesel Engine Technical Data
Engine Model Cummins 4BT3.9-G2
No. of Cylinders 6 cylinders, Vertical in line
Aspiration Turbocharged
Bore×Stroke 102mm x120mm
Displacement 3.9L
Compression ratio 17.3:1
Prime/Standby Power/Speed 40KW/44KW / 1800rpm
Speed Governor electrical
Cooling System Forced water cooling cycle
Fuel Consumption at 100% Load 221g/kwh@1800rpm
Alternator Data
Optional brands Stamford/Leroy Somer/Marathon/WellPower
Prime power 45KVA
Frequency/speed 60Hz/1800RPM
Exciter type Single bearing, Brushless, Self-excited with AVR
Power factor 0.8
Voltage adjust range ≥5%
Voltage regulation NL-FL ≤±1%
Insulation Grade H
Protection Grade IP23
Control Panel
Optional brands Deespea/Smartgen/ComAp




Multifunctional Yangdong Genset 40KW , Durable Diesel Powered Generator 0Multifunctional Yangdong Genset 40KW , Durable Diesel Powered Generator 1Multifunctional Yangdong Genset 40KW , Durable Diesel Powered Generator 2
