Power Silent Trailer Type Generator 300kw Practical Weatherproof
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
WeChat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | Trailer Diesel Genertor | Type | Trailer |
|---|---|---|---|
| Engine | CUMMINS PERKINS | Options | Automatic Transfer Switch |
| Generator Type | Household Power Portable Trailer Diesel Generator | Color | Customers' Request |
| Controller | Smartgen DeepSea | Keyword | Gnerator |
| Control Panel | LCD Digital Display | Use | Industrial And House |
| Highlight | Trailer Type Generator 300kw,Trailer Type Generator Practical,Weatherproof Power Silent Generator |
||
Product Description
Good Price Trailer Silent Diesel Generator 300kw Power With Diesel Engine Diesel Generator
Diesel generator Specifications
1. Powered by reliable engines
2. Branded alternator
3. Open type, silent type or super silent type generator
4. ISO, CE certified
Genset specs:
Engine Brands: Powered by Cummins,Powered by Perkins,Powered by Lovol,Powered by Deutz,Powered by Doosan, Powered by Mitsubishi, Powered by Kubota or other reliable Chinese engines such as Fawde and Laidong.
Rated output: 2 to 2,000kW/2 to 2,500kVA
Rated voltage: L-N 110 to 277V, L-L 220 to 480V
Rated frequency: 50/60Hz
Cooling method: closed water-cooled or air-cooled
Starting method: electric start or recoil start
Rated speed: 1,500/1,800/3,000/3,600rpm
Noise level: 56 to 75dB, 7 meters away
Alternator:
Brands: By Stamford, By Leroy Somer, By Mecc Alte and Keypower brushless alternator
Rated output: 8 to 2,000kW/10 to 2,500kVA
Rated voltage: L-N 110 to 277V, L-L 220 to 480V
Rated frequency: 50/60Hz
Phase: 3-phase, 4-wire or 1-phase, 2-wire
Connection: y or other type connection
Rated speed: 1,500/1,800rpm
Excitation: harmonic excitation or phase compound or brushless
Voltage regulation: AVR automatic
1.0% voltage regulation in static conditions (maximum)
Protection class: IP23
Control panel: Deepsea, ComAp, Smartgen
| The main parameters of 300kw diesel generator | |
| The model of the unit: | CN300GF |
| Power: | 300KW/375KVA |
| Rated voltage: | 230V/400V(adjustable) |
| Rated current: | 540A |
| Rated frequency: | 50Hz/60Hz |
| The factor of rated power | COS=0.8(lag) |
| The regulating rate of steady voltage: | ≤±0.5% |
| The regulating rate of instantaneous voltage: | ≤-10%/ +15% |
| The time of steady voltage: | ≤1.5sec |
| The waving rate of voltage: | ≤0.5% |
| The regulating rate of steady frequency: | ≤3% |
| The regulating rate of instantaneous frequency: | ≤±5% |
| The time of steady frequency: | 3sec |
| The waving rate of frequency: | ≤0.25% |
| The waste of fuel with full load: | 206g/kw/h |
| size(mm): | 3200*1050*1750 |
| weight: | 3000KGS |
| The main parameters of the engine for 300kw diesel generator | |
| Brand: | Cummins |
| Model: | NTA855-G2A |
| Type: | four strokes, waste gas turbine boost,direct spurting type |
| Cooling way: | water cooling |
| With Type: | L type |
| Bore *Trip : | 140mm*152mm |
| Displacement | 14L |
| Lubricating oil capacity: | 38L |
| Cylinder: | 6cylinders |
| Rotating speed: | 1500r/min or 1800r/min |
| The regulation of rotating speed: | Electronic speed |
| Starting way: | DC24V starting with electricity |
| The main parameters of alternator for 300kw diesel generator | |
| Brand: | Stamford,Marathon,Sdanford |
| Type: | brushless (AVR automatic voltage regulating) |
| The connecting way of the phase: | three phases four lines |
| Insulation degree: | H degree |
| Grading Protection: | IP22 |
