Industrial Mobile Trailer Generator , 30KW Diesel Powered Generator Portable

Place of Origin China
Brand Name CNMC
Certification EPA/CE/ISO And So On
Model Number CN24GF
Minimum Order Quantity 1 set
Price USD 2500-3000/set
Packaging Details wooden case packing
Delivery Time 7 days
Payment Terms L/C, T/T
Supply Ability 1000 sets per week

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

WeChat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Trailer Diesel Genertor Type Trailer
Engine CUMMINS PERKINS Options Automatic Transfer Switch
Generator Type Household Power Portable Trailer Diesel Generator Color Customers' Request
Controller Smartgen DeepSea Keyword Gnerator
Control Panel LCD Digital Display Use Industrial And House
Highlight

Industrial Mobile Trailer Generator

,

Mobile Trailer Generator Portable

,

30KW Diesel Powered Generator Portable

Leave a Message
Product Description

Brand Diesel Engine 30KW Trailer Diesel Generator Set Super Silent Trailer Diesel Generator Set

Diesel generator Specifications
1. Powered by reliable engines
2. Branded alternator
3. Open type, silent type or super silent type generator
4. ISO, CE certified

Genset specs:
Engine Brands: Powered by Cummins,Powered by Perkins,Powered by Lovol,Powered by Deutz,Powered by Doosan, Powered by Mitsubishi, Powered by Kubota or other reliable Chinese engines such as Fawde and Laidong.
Rated output: 2 to 2,000kW/2 to 2,500kVA
Rated voltage: L-N 110 to 277V, L-L 220 to 480V
Rated frequency: 50/60Hz
Cooling method: closed water-cooled or air-cooled
Starting method: electric start or recoil start
Rated speed: 1,500/1,800/3,000/3,600rpm
Noise level: 56 to 75dB, 7 meters away
Alternator:
Brands: By Stamford, By Leroy Somer, By Mecc Alte and Keypower brushless alternator
Rated output: 8 to 2,000kW/10 to 2,500kVA
Rated voltage: L-N 110 to 277V, L-L 220 to 480V
Rated frequency: 50/60Hz
Phase: 3-phase, 4-wire or 1-phase, 2-wire
Connection: y or other type connection
Rated speed: 1,500/1,800rpm
Excitation: harmonic excitation or phase compound or brushless
Voltage regulation: AVR automatic
1.0% voltage regulation in static conditions (maximum)
Protection class: IP23
Control panel: Deepsea, ComAp, Smartgen



Model   CN30GF
Standby Power KVA 42
KW 33
Prime Power KVA 37.5
KW 30
Frequency Hz 60
Voltage V 208/416
Rated speed rpm 1500
Cummins 4BT3.9-G2: in-line, 4 cylinder, 4 cycle,natural aspirate diesel engine
Bore X Stroke (mm) 102x120
Displacement (L) 3.9
Compression ratio 16.5:1
Rated speed (rpm) 1500/1800
Prime power (kW) 36/40
Standby power (kW) 40/45
Fuel injection pump AD injection pump
Governor GAC electric governor / RSV mechanical governor
Steady speed droop ≤1% (Electrical governor) / ≤5% (Mechanical governor)
Lubricant capacity (L) 11
Coolant capacity (L) 7.2 (engine only)
Net weight (kg) 320
Gross weigh (kg) 340
Overall dimension (LXWXH) (mm) 765X582X908
Coolant intake size ¢58 mm
Coolant outlet size ¢45 mm
Flywheel/Flywheel housing SAE3#/ SAE3#
Cooling system Forced water cooling cycle
Performance data
Standard air intake temperature 25℃
Air intake pressure (kPa) 100
Standard light diesel 0# / -10# light diesel
Fuel intake temperature 40
Air intake restriction (mmHg) 251
Exhaust back pressure (mmHg) 76
Lubrication oil 15W40-CF4 Upgrade
