3 Phase Trailer Type Generator Multifunctional Practical 150kw

Place of Origin China
Brand Name CNMC
Certification EPA/CE/ISO And So On
Model Number CN150GF
Minimum Order Quantity 1 set
Price USD 2500-3000/set
Packaging Details wooden case packing
Delivery Time 7 days
Payment Terms L/C, T/T
Supply Ability 1000 sets per week

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

WeChat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Trailer Diesel Genertor Type Trailer
Engine International Brand Engine And Chinese Brand Engine Options Automatic Transfer Switch
Generator Type Household Power Portable Trailer Diesel Generator Color Customers' Request
Controller Smartgen DeepSea Keyword Diesel GENERATOR
Control Panel LCD Digital Display Certification CE/EAP/ISO
Highlight

3 Phase Trailer Type Generator

,

Trailer Type Generator Multifunctional

,

Practical 3 Phase Generator Trailer

Leave a Message
Product Description

Good Price Three Phase Silent Trailer Diesel Generator 150kw Diesel Generator Power With Diesel Engine

Main Assemblies:
3 Phase Trailer Type Generator Multifunctional Practical 150kw 0

  • 1, Diesel Engine (Cummins Brand)
  • 2, Generator/Alternator (With AVR)
  • 3, Standard Control Panel (Ordinary Type, LCD Type, ATS Type )
  • 4, Common Base with Canopy(Including Base Oil Tank)

Standard Accessories:

  • 1, Starting Battery and Connector Wire
  • 2, The Vibration Reduction Rubber Gasket
  • 3, Silencer
  • 4, Exhaust Elbow
  • 5, 8-hour Oil Tank
  • 6, Spare Part Case
  • 7, Technical Data
  • 8, Water Tank Radiator,The belt-driving Cooling Fan ,Fan Safety Shield
  • 9, Dry-type Air Filter
  • 10, Fuel Filter
  • 11, Lubricating Oil Filter
  • 12, Starting Motor
  • 13, Self-charging Generator
  • 14, Frequency Meter/Water-thermometer/Oil Pressure Gauge/Battery Voltmeter

Optional Accessories:

  • 1, Preheating Start System
  • 2, Diesel Engine Thermal Protection System
  • 3, Jacket Heater
  • 4, Speeding, High Temperature, High Oil Temperature, Low Pressure Alarm System
  • 5, Breaker
  • 6, Antifreeze Liquid
  • 7, Ground Wire
  • 8, Water Temperature Safety Device
  • 9, Machine Oil

Service Conditions:

  • -- Ambient Temperature: -25°C~40°C
  • -- Altitude: not exceed 1000 Meter
  • -- Rated Voltage: 230/380V or any voltage between 220-440V
  • -- Rated Frequency: 50Hz/60Hz
  • -- Insulation Class: B/F/H
  • -- Working Duty: S1(Continuous)
  • -- Humidity: Lower than 95%
Diesel Generator Application

We produce and export 8-2000kw diesel generator sets. Diesel generator sets are widely used in field construction, high-rise buildings, schools, hospitals, industrial and mining enterprises, farms, villages and other places where electricity is needed.
Genset model CN150GF
Prime power (KW/KVA) 150/188
Standby power (KW/KVA) 165/206
Frequency & voltage 50HZ, 400V
No. of Phase 3
Genset type Soundproof/silent type
Reference Dimension & Weight
(W*H, mm)/KGS
3500*1100*1800; 2100kgs

DIESEL ENGINE
Engine CUMMINS brand 6CTAA8.3-G2
Rated output 183KW
Rated Speed 1500RPM
Engine Type Vertical in-line, four stroke
No. of cylinder 6
Bore*stroke 114*135mm
Aspiration method Turbocharged after air-air cooled
Governor Electrical
Starting method Electric starting
Cooling method Forced water cooled
Displacement 8.3L
Compression ratio 16.5:1
Fuel consumption 205g/kw.h
Speed stability ≤5%
Total lubrication system capacity 24L
Coolant capacity(without radiator) 12.3L
Starter motor DC24V
Alternator AC24V
ALTERNATOR
Alternator brand & model Stamford/China reputed brand
Type Brushless & self-excited
No. of phase 3
Voltage 400V
Frequency 50HZ
Power Factor 0.8
Insulation Grade H
Protection Grade IP22/23
Altitude ≤1000m
